LED Full Body High Bay V2 Series – 4K/5K – 90W-425 Watt – Up to 60,629 Lumens – UL Listed – Dimmable – 5 Year Warranty
★★★★★ /5
0 review
LED Full Body High Bay V2 Series – 4K/5K – 90W-425 Watt – Up to 60,629 Lumens – UL Listed – Dimmable – 5 Year Warranty
★★★★★ 0.0/5
0 reviews
Model: 07-LEDFHB-K-MVDIM-V2
Kelvin Temp: 4000 Kelvin, 5000 Kelvin
Occupancy Sensor: None, ODS=Microwave, OS=Passive Infrared
Voltage: UNV 120-277, 347-480
Wattage: 90, 135, 180, 215, 265, 320, 425
90-425W LED FULL BODY HIGH BAY V2 SERIES
The V2 full-body, premium-performance LED high bay luminaire. It is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a painted, steel housing, the V2 High Bay provides durability and high performance. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays. FEATURES
• Available in 4000k (neutral white) and 5000k (cool white) color temperature.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumens output (L70).**
• Delivers from 12,193 lumens (140 lumens per watt, LPW) to 60,629 lumens (142 LPW).*
• Power factor > 0.90.
• 0-10vdc dimming drivers are standard.
• Total harmonic distortion < 20%
• Color rendering index > 80.
• Painted steel housing.
• Easy installation in new construstion or retrofit.
• Chain-mount kits (includes v-hooks and ⅛“ thick, 1-meter long chain) are standard.
• Options include lenses (clear & diffused), wire-guard kits, surface-mounting kits, pendant-mounting kits, and cable-mounting kits.
• Available in 4000k (neutral white) and 5000k (cool white) color temperature.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumens output (L70).**
• Delivers from 12,193 lumens (140 lumens per watt, LPW) to 60,629 lumens (142 LPW).*
• Power factor > 0.90.
• 0-10vdc dimming drivers are standard.
• Total harmonic distortion < 20%
• Color rendering index > 80.
• Painted steel housing.
• Easy installation in new construstion or retrofit.
• Chain-mount kits (includes v-hooks and ⅛“ thick, 1-meter long chain) are standard.
• Options include lenses (clear & diffused), wire-guard kits, surface-mounting kits, pendant-mounting kits, and cable-mounting kits.
* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.
**L70 hours are IES TM-21-11 calculated hours.
MOUNTING
• Chain mounting with V-hooks is standard.
• Optional surface mounting kit provides attachment to flat ceilings.
• Optional pendant mounting kit provides pendant attachment to junction boxes.
• Optional cable mounting kits provide suspension at two lengths (i.e., 3 & 5 meters).
• Chain mounting with V-hooks is standard.
• Optional surface mounting kit provides attachment to flat ceilings.
• Optional pendant mounting kit provides pendant attachment to junction boxes.
• Optional cable mounting kits provide suspension at two lengths (i.e., 3 & 5 meters).
WARRANTY/LISTING
• cULus listed for damp locations in ambient temperatures from -20°C to 50°C (-4°F to 122°F).
• Complies with FCC Part 15, class B.
• Complies with IEEE C.62.41-1991, input transient protection (2.5kV).
• 5-year warranty
Description
Features
Warranty & Listings
Description
90-425W LED FULL BODY HIGH BAY V2 SERIES
The V2 full-body, premium-performance LED high bay luminaire. It is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a painted, steel housing, the V2 High Bay provides durability and high performance. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays.Features
FEATURES
• Available in 4000k (neutral white) and 5000k (cool white) color temperature.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumens output (L70).**
• Delivers from 12,193 lumens (140 lumens per watt, LPW) to 60,629 lumens (142 LPW).*
• Power factor > 0.90.
• 0-10vdc dimming drivers are standard.
• Total harmonic distortion < 20%
• Color rendering index > 80.
• Painted steel housing.
• Easy installation in new construstion or retrofit.
• Chain-mount kits (includes v-hooks and ⅛“ thick, 1-meter long chain) are standard.
• Options include lenses (clear & diffused), wire-guard kits, surface-mounting kits, pendant-mounting kits, and cable-mounting kits.
• Available in 4000k (neutral white) and 5000k (cool white) color temperature.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumens output (L70).**
• Delivers from 12,193 lumens (140 lumens per watt, LPW) to 60,629 lumens (142 LPW).*
• Power factor > 0.90.
• 0-10vdc dimming drivers are standard.
• Total harmonic distortion < 20%
• Color rendering index > 80.
• Painted steel housing.
• Easy installation in new construstion or retrofit.
• Chain-mount kits (includes v-hooks and ⅛“ thick, 1-meter long chain) are standard.
• Options include lenses (clear & diffused), wire-guard kits, surface-mounting kits, pendant-mounting kits, and cable-mounting kits.
* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.
**L70 hours are IES TM-21-11 calculated hours.
MOUNTING
• Chain mounting with V-hooks is standard.
• Optional surface mounting kit provides attachment to flat ceilings.
• Optional pendant mounting kit provides pendant attachment to junction boxes.
• Optional cable mounting kits provide suspension at two lengths (i.e., 3 & 5 meters).
• Chain mounting with V-hooks is standard.
• Optional surface mounting kit provides attachment to flat ceilings.
• Optional pendant mounting kit provides pendant attachment to junction boxes.
• Optional cable mounting kits provide suspension at two lengths (i.e., 3 & 5 meters).
Warranty & Listings
WARRANTY/LISTING
• cULus listed for damp locations in ambient temperatures from -20°C to 50°C (-4°F to 122°F).
• Complies with FCC Part 15, class B.
• Complies with IEEE C.62.41-1991, input transient protection (2.5kV).
• 5-year warranty
