360 Degree PIR Line Voltage Occupancy Sensor

Rated 0 out of 5

Model: 13-OCO52V

View Spec Sheet

360° PIR LINE VOLTAGE OCCUPANCY SENSOR

The 360° passive infrared (PIR) occupancy sensors turn lighting systems on and off based on occupancy and ambient light levels. The light level feature keeps lights from turning on if the ambient light level is sufficient. The sensors can be configured to turn lighting on, and hold it on as long as the sensor detects occupancy. After no movement is detected for a specified time the lights are switched off.

ELECTRICAL SPECIFICATIONS Input • Input Voltages: Universal120 or 277VAC, 60Hz (User selectable with (2) wire jumpers provided) • Input Frequencies: 60Hz ±2% • Input Protection: Provided by Service Panel rated at 20 amps maximum Output • Output Voltages: 120 or 277VAC (60Hz) • Efficiency Rating: 98% at full rated load (line) • Waveform: Sinusoidal (digitally controlled) • Static Voltage: ±5% during battery discharge. 0-100% linear load. • Output Frequencies: 60Hz. ±0.3Hz during emergency cycle • Output Distortion: Less than 3% THD (linear load) • Transfer Time: Less than 1.0 second. • Load Power Factor Range: 0.88 Lead to 0.88 Lag. • Minimum Loading: 0% of rated system capacity. • Output Protection: Circuit breaker. HOUSING Heavy duty steel cabinet is finished in white based-on powder providing scratch and corrosion resistance. MOUTING Designed for mounting to walls by means of keyhole slots provided in the back of the unit housing. BATTERY Battery: Sealed Lead Calcium (10 year life) Battery Voltage: 72VDC for 03-LPS-1150, Runtime: 90-minutes standard- based on battery performance at (25°C). Other runtimes available, consult factory. Battery Protection: Low Voltage Battery Disconnect protects the battery from being severely damaged by deep discharge during prolonged power failures. Reverse Polarity, DC Overload and Short Circuit Protection provided by a DC input breaker and fuse. CHARGER Charger Type: Fully automatic, temperature compensated, dual-mode charger Power Consumption: (charger only) 73W maximum (6.7W in standby) for 03-LPS-1150 model. Recharge Duty Cycle: Meets UL924 requirements Controls: Momentary test switch, AC-ON, Charge-ON and Inverter-ON LED indicator lights Safety Circuitry: AC Lockout prevents battery discharge prior to initial unit power-up. Brownout Protection automatically switches the unit to emergency mode when utility voltage is significantly reduced.
