Cast aluminum housing with dark bronze, powder coat finish.
Diffused polycarbonate lens.
One ½” NPT threaded opening.
Mounting
Easy installation in new construction or retrofit applications.
Electrical
0-10vdc dimming drivers are standard.
Universal 120-277 AC voltage (50-60Hz) is standard.
Power factor > 0.90.
Total harmonic distortion < 20%.
Integral photocell is standard.
Optical System
Field selectable 3000k (warm white), 4000k (neutral white), and 5000k (cool white) color temperatures.
Long-life LEDs provide at least 70% of initial lumen output (L70) for > 156,000 hours of operation, and at least 90% of initial lumen output (L90) for > 47,000 hours of operation.**
LED chromaticity based on < 5-step ANSI quadrangles.
LED color maintenance < 0.003 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
Provides a range of 1,900 to 3,300 nominal lumens and 126 to 145 nominal lumens per watt (lm/W).
Color rendering index (Ra) > 80.
Code Compliance
cULus listed for wet locations in ambient temperatures from -20°C to 50°C (-4°F to 122°F).
