Square LED Slim Bollard – Lumen & Kelvin Selectable

Model: 06-BOLS-Sxx-332821L-5CCT
Ask for Price

Request product pricing

Call for Pricing now: 833-504-9980
or
This field is for validation purposes and should be left unchanged.
Name(Required)
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form

Our lighting professional will call you to provide pricing.

This sleek bollard light delivers durable outdoor performance with field-selectable lumen output and 5CCT flexibility for a variety of commercial and landscape applications. Featuring a premium powder-coated aluminum housing in dark bronze or black, it offers field-selectable lumen output and 5CCT adjustability to adapt to a wide range of pathways, landscape, and commercial exterior applications. Standard features include 0–10V dimming, integrated photocell control, IP65 wet-location protection, and IK08 impact resistance.

Housing
  • Premium powder-coat, aluminum, dark bronze or black housing.
Electrical
  • Operating temperature (ambient): -40°C to 50°C (-40°F to 122°F).
  • Universal 120-277V AC voltage (50-60Hz) is standard.
  • 0-10VDC dimming drivers are standard.
  • Integrated photocell is standard. Photocell can be enabled or disabled by switch.
  • Input transient surge protection = 4kV.
  • Power factor > 0.90.
  • Total Harmonic distortion < 20%.
Optical System
  • High-impact, Polycarbonate Lens.
  • Field selectable 2700k (warm white), 3000k (warm white), 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.
  • Selectable output delivers 2,010 to 3,291 nominal lumens.
  • Long-life LEDs provide 167,000 hours of operation with at least 70% of initial lumen output (L70), and 51,000 hours with at least 90% of initial lumen output (L90).
  • LED color maintenance < 0.0008 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
  • Color rendering index > 80.
Mounting
  • Anchor Bolt mount kit (included).

Code Compliance

  • cULus listed for wet locations.
  • Complies with FCC part 15, class A.
  • IP65 rated for ingress protection.
  • IK08 rated for impact protection.
