2×2 LED Back-Lit Flat Panel Lumen & Kelvin Field Selectable

0 review

2×2 LED Back-Lit Flat Panel Lumen & Kelvin Field Selectable

0 reviews
Model: 05-PNL2x2-LKFS
Accessories: None, DWS-010-D = 0-10V Dimmer, Decora Switch, DWS-010-T = 0-10V Dimmer, Toggle Switch, IP710-DLZ = 0-10V Dimmer, Button Switch
Emergency Drivers: None, EM10, EM13, EM5
Add to Quote

▪Field selectable 3500k (warm/neutral white), 4000k (neutral white), & 5000k (coolwhite) color temperatures*
▪Long-life LEDs provide 144,000 hours of operation with at least 70% of initial lumenoutput (L70), and 44,000 hours with at least 90% of initial lumen output (L90)**
▪ Selectable lumen outputs range from 2,700 to 4,000 nominal lumens*
▪ Uniform illumination with no visible LED pixilation
▪ Universal 120-277 AC voltage (50-60Hz) is standard
▪ 0-10vdc dimming drivers are standard
▪ Power factor > 90
▪ Total harmonic distortion < 20%
▪ Color rendering index > 80
▪ Aluminum frame and steel housing backplate
▪ PMMA (polymethyl methacrylate) LED lenses for optimal light distribution,
efficiency and longevity
▪Easy installation in new construction or retrofit
▪ Standard earthquake clips provide secure installation in grid ceilings
▪ Optional emergency drivers are available
▪ Standard mounting options include recessed mounting in grid ceilings, orsuspended mounting using attached hanging brackets. For mounting in plaster or other hard ceiling, see Mounting Kits

* Contact factory for other color temperatures and lumen packages
** L70 hours are IES TM-21-11 calculated hours

▪cULus for damp locations and insulated ceilings (Type IC-rated).Suitable for ambient temperatures from -20°C to 40°C (-4°F to 104°F)
▪ Flicker-free per IEEE1789-2015 (no observable adverse effects of flickerat 100% light output level)
▪ Complies with FCC Part 15, class B
▪ Surge immunity protection = 1kV
▪ 5-year warranty of all electronics and housing
