Versatile LED Emergency Backup Driver – UL Recognized for Factory Installation – 36W (IN) – 20W (OUT) – 120-277V (IN) – 180-320V (OUT)
Versatile LED Emergency Backup Driver – UL Recognized for Factory Installation – 36W (IN) – 20W (OUT) – 120-277V (IN) – 180-320V (OUT)
VERSATILE LED EMERGENCY BACKUP DRIVER
Provides 180-320VDC (or 120-230VAC) constant output to the load during emergency mode operation. For use with switched or unswitched fixtures. Can be used with LED lamp loads of up to 20W. ELECTRICAL
• Universal 120-277V, 50/60 Hz input
• Charge/Power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
• Long-life, maintenance free, rechargeable NiCad battery
• Output short/overcurrent protection: Electronic limiting, with normal operation resuming upon removal of fault
• 90 Minute minimum emergency operating time over full temperature range
• 24 Hour maximum battery recharge time
• LED illuminated and remote mounted test switch
• Durable painted steel construction in red/orange finish
• Provided with 18” fl ex conduits on both ends
• Suitable for installation inside or top of the fixture
• UL Recognized for factory installation
• Suitable for damp locations (0°C – 55°C)
• 5-Year Warranty on all electronics and housing
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes
VERSATILE LED EMERGENCY BACKUP DRIVER
Provides 180-320VDC (or 120-230VAC) constant output to the load during emergency mode operation. For use with switched or unswitched fixtures. Can be used with LED lamp loads of up to 20W. ELECTRICAL
• Universal 120-277V, 50/60 Hz input
• Charge/Power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
• Long-life, maintenance free, rechargeable NiCad battery
• Output short/overcurrent protection: Electronic limiting, with normal operation resuming upon removal of fault
• 90 Minute minimum emergency operating time over full temperature range
• 24 Hour maximum battery recharge time
• LED illuminated and remote mounted test switch
• Durable painted steel construction in red/orange finish
• Provided with 18” fl ex conduits on both ends
• Suitable for installation inside or top of the fixture
• UL Recognized for factory installation
• Suitable for damp locations (0°C – 55°C)
• 5-Year Warranty on all electronics and housing
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes
